| Frame | Carbon MTB Frame FM-650B M20SL,C-T 15"UD 1.5"TOP,FD/Direct Mount ,￠27.2mm/BB-92 QR/135mm/L,or12mm/142mm/L |
| Fork | 27.5" Carbon Fork, 11/8'*1.5'*AC485mm/L.M15*100mm. QR,ID22.2*OD28.6mm |
| Handle Bar | X-Zenith / HB-XR1.0SL, UD Carbon Riser Bar - Super Light Version 31.8x660mm |
| Stem | X-Zenith / ST-XS1.0SL, UD.MAT.31.8*90L Carbon Stem, Carbon Faceflate Red |
| Seat Post | X-Zenith / SP-XS1.0SL, UD/RED Carbon Seat Post,27.2*350mm/L 0 degree/OFFSET |
| Saddle | WCS STREEM V2, WCS, Leather, Nylon + CF Shell ,Hollow Titanium Rail , WHITE |
| Front Derailleur | |
| Rear Derailleur | 15'REAR DERAILLEUR XX1 RED '11S 'CARBON |
| Shift Lever:SET: | DB XX OBK FRT DIR 800 / RER DIR 'DB XX OBK FRT DIR 750 'GLOSS BLACK 'CARBON 'TITANIUM 'CLAMPS (DB-ACC-) AND ROTORS (RT-) MUST BE ORDERED SEPERATELY |
| Brake Lever: | XX CLAMP LEFT / RIGHT BLACK FOR MATCHMAKER (MMX) |
| Disc Rotor F/R | ASSY DB ROTOR/BOLTS HSX 160 RED TI |
| Cranketset | FRONT CHAINWHEEL, FC-M785, DEORE XT, HOLLOWTECH 2, FOR REAR 10-SPEED W/BB PARTS, 175MM 40X28T W/O CG, SILVER, BULK |
| Bottom Bracket | Shimano Saint BB71-41A Press-Fit Bottom Bracket MTB (92mm) |
| Cassette Sprocket | XX1 CS 'XG 1199 10-42 '10-42 11 SPEED X GLIDE CASSETTE 'SILVER |
| Chain | Chain PC XX1, 118 Links with Power Lock, 11 speed, 50 Pieces 'SILVER |
| Wheel Set: | X-Zenith / WH-XX65C Carbon Red, Freehub for SRAM XX1 Mountain Wheelset, 650b", WH-XX65C 27.5" Rim, F/R: 28 Holes, XB-XX5.3 Hub/Black, Pillar PSR2015 Spokes, Skewer: QR-XX6.0 (black), 1742g / per set (Front + Rear), • Rim: Carbon Red • Hub: black/Red • |
| Tire | 27.5 X2.00 M324 170TPI, FOLDING. SILKWORM (360g) |
| Axle / Skewer ,QR | QR-XX2.1 12mm*OLD/142mm *P1.5 AL7075 360Degree China is empty/Lever US:13/21415 TAIWAN:100214698 79g Lever Color/RED |
| Frame : Carbon MTB Frame FM-650B M20SL,C-T 15"UD 1.5"TOP,FD/Direct Mount ,￠27.2mm/BB-92 QR/135mm/L,or12mm/142mm/L | Fork : 27.5" Carbon Fork, 11/8'*1.5'*AC485mm/L.M15*100mm. QR,ID22.2*OD28.6mm |
| Handle Bar : X-Zenith / HB-XR1.0SL, UD Carbon Riser Bar - Super Light Version 31.8x660mm | Stem : X-Zenith / ST-XS1.0SL, UD.MAT.31.8*90L Carbon Stem, Carbon Faceflate Red |
| Seat Post : X-Zenith / SP-XS1.0SL, UD/RED Carbon Seat Post,27.2*350mm/L 0 degree/OFFSET | Saddle : WCS STREEM V2, WCS, Leather, Nylon + CF Shell ,Hollow Titanium Rail , WHITE |
| Rear Derailleur : 15'REAR DERAILLEUR XX1 RED '11S 'CARBON | Shift Lever : DB XX OBK FRT DIR 800 / RER DIR 'DB XX OBK FRT DIR 750 'GLOSS BLACK 'CARBON 'TITANIUM 'CLAMPS (DB-ACC-) AND ROTORS (RT-) MUST BE ORDERED SEPERATELY |
| Brake Lever (F/R) : XX CLAMP LEFT / RIGHT BLACK FOR MATCHMAKER (MMX) | Disc Rotor : ASSY DB ROTOR/BOLTS HSX 160 RED TI |
| Crankset : FRONT CHAINWHEEL, FC-M785, DEORE XT, HOLLOWTECH 2, FOR REAR 10-SPEED W/BB PARTS, 175MM 40X28T W/O CG, SILVER, BULK | Bottom Bracket : Shimano Saint BB71-41A Press-Fit Bottom Bracket MTB (92mm) |
| Cassette Sprocket : XX1 CS 'XG 1199 10-42 '10-42 11 SPEED X GLIDE CASSETTE 'SILVER | Chain : Chain PC XX1, 118 Links with Power Lock, 11 speed, 50 Pieces 'SILVER |
| Wheels : X-Zenith / WH-XX65C Carbon Red, Freehub for SRAM XX1 Mountain Wheelset, 650b", WH-XX65C 27.5" Rim, F/R: 28 Holes, XB-XX5.3 Hub/Black, Pillar PSR2015 Spokes, Skewer: QR-XX6.0 (black), 1742g / per set (Front + Rear), • Rim: Carbon Red • Hub: black/Red • | Tire : 27.5 X2.00 M324 170TPI, FOLDING. SILKWORM (360g) |
| Quick Release : QR-XX2.1 12mm*OLD/142mm *P1.5 AL7075 360Degree China is empty/Lever US:13/21415 TAIWAN:100214698 79g Lever Color/RED |
